Description
Sheet thickness 8 mm
cutting length 3.500 mm
Delivery time approx. 6-8 weeks from order placement
sheet thickness: 8 mm
cutting length: 3.500 mm
back gauge: 1.000 mm
throat: 450 mm
stroke: 16 – 40 H/min
cutting angle: 0,5°/1°/1,7°
cutting gap adjustment: 0,1 – 1,4 mm
motor: 14,7 kW
length: 4.300 mm
width: 2.100 mm (without support arm)
height: 1.650 mm
weight: 10.500 kg
Cradle guided machine with cutting angle adjustment Cutting length limitationTrapezoidal spindle for backgauge1x side stop2x table support arms Balls in the table18x hold-downs Instruction manual in GERMAN Does not comply with the German UVV & Austrian AMVO
