Description
Amada HFT 50-20 CNC Press brake
| Strength | 50 T |
| Folding length | 2085 mm |
| Distance between uprights | 2665 mm |
| CNC | CD2005 AMADA |
| Throat | 420 mm |
| Vertical stroke | 200 mm |
| Working speed | 10 mm/s |
| Axis number | 4 |
| Motor power | 6 kW |
| Amada HFT 50-20 | |
| Length x width x height | 2950.0 × 1580.0 × 2450.0 |
| Weight | 4850 kg |
| Worked hours | 41764 hours |
AMADA HFT 50-20 CNC press brake was built in 2007.
The machine was regularly serviced, working on sheet metal 0.5-0.75.
The press is offered with a basic set of tools.
– CNC control: CD2005 AMADA
– number of operating hours: 41 764 h
– maximum baling force: 50 t
– minimum baling force: 4 t
– number of controlled axes: 4
– length of the ironing bar: 2090 mm
– maximum bending length: 2085 mm
– length between stands : 2665 mm
– installation height: 470 mm
– working table width: 60 mm
– table height: 960 mm
– stroke: 200 mm
– working speed: 1-10 mm / s.
– return stroke speed: 1-100 mm / s.
– maximum pressure: 270 bar
– oil capacity: 55 l
– rear bumper: type A
– mains voltage V / H: 400/50
– machine dimensions (L x W x H): 2950 x 1580 x 2450 mm
– total width with control: 1820 mm
– total width with light curtain: 1970 mm
– weight: 4850 kg
