Description
BLM ELECT63B Fully electric tube bending machine – Year 2022
Max. tube Ø 63 mm
Total power 18 kW
Weight 6700 kg
• Near new, very little use due to a change in contracted works.
• Produced less than 150 parts.
• The bender has an extended bed and is fully optioned, equipped with a laser part positioner.
No experience is needed to use ELECT: All movements are managed by an electric axis. Set-up is automatic, and all position and power parameters are saved together with the part program.
Technical Information
Round tube max. bending capacity
Diameter – 2.48″ (63mm)
Thickness – .157″ (40mm)
Bending direction RH or LH convertible
Axes 9
X Accuracy +/- 0.05 mm
Y Accuracy +/- 0.05 degrees
Z Accuracy +/- 0.05 degrees
Clamp edge 81.10″ / 2060 mm
Mandrel extractor 177.17″ / 4500 mm
Max. installed power 18.0 kW
Average drawn power 4.5 kW
Noise level 65 dB(A)
Weight 6700Kg
Round or special section tubes
Not only round, square, or rectangle, with ELECT you can also bend special profiles. The modular die maintains uniformity along the entire curve, whatever section you are working on with the certainty of always having accurate results.
All parts are precise and repeatable
You can always count on repeatability and geometric precision of the bent part, regardless of material imperfections. Using special programs that can be selected by the operator, ELECT compensates variations in material quality and dimensional accuracy.
Quality is power under your control
Small sections even for narrow radii. High-quality appearance. No waste.
The machine can be equipped with different levels of carriage boost power (up to 60,000 N). The boost can be continuously controlled over the entire bending sequence controlling the material behaviour, such as elongation and spring-back. This ensures maximum process control to the last bend.
Quick changeover
Change the bending tools quickly and easily. With the quick-change system you exchange tooling in just 3 minutes. The set-up is automatic, and you are immediately ready for a new production.
Take no risks – choose your safety features
The pedal prevents dropping the parts at the end of the loading and unloading operations. The two-hand activation control prevents the operator from coming into contact with moving parts. To combine safety and efficiency, the laser scanner allows you to choose the size of the work area based on the size of the part you are working on. The machine is provided with the CE declaration of conformity and the user and maintenance manual.
