BUCK TBFZ 3000 CNC – Year 2001

Contact us for price

Description

BUCK TBFZ 3000 CNC – Year 2001
CNC deep hole drilling machine – 5 axes

– Tapping and drilling operations with the use of conventional tools
– Deep hole drilling works with the use of single lip metal drills e.g. cooling channels, ejectors, oil and lubrication holes
– Milling work with roughing and finishing tools

The machine can be inspected under power. Subject to prior sale. Sold under exclusion of any warranties and within the scope of our terms and conditions. All information without guarantee.

Manufacturer: BUCK
Model: TBFZ 3000 CNC
Year of manufacture: 2001
Control: HEIDENHAIN

Operating hours: approx. 43.000 h

Technical data
traverse paths:
X-axis: longitudinal 1,000 mm, Y-axis: vertical 1,500 mm, Z-axis: transverse 2,000 mm.
B-axis: 0-360°, rotary table
A-axis: +/- 20°, swivel arm (measuring system Renishaw scale)
Max. tool length changer: 300 mm
Max. tool diameter changer: 100 mm

Rotary table:
Clamping surface: 2,000 x 1,800 mm
Table load: up to 20.000 kg

Weight: approx. 18,500 kg
Space requirement: 6, 8 m length x 6, 5 m width x 3, 5 m height
Connected load: mains connection 400 V/50 Hz, power consumption: 55 KVA

Equipment:
20-fold tool changer
CNC controlled, automatic swiveling and positioning drill bush carrier incl. tapping unit and chip lock
CNC swivel arm
– as stepless positioning axis controlled deep drilling/milling unit
– Clamping is done hydraulically
– zero point calculation via CNC
CNC rotary table
– rotary table controlled as stepless positioning axis (0-360°)
scraper belt conveyor 1.000 mm
Heidenhain linear path measuring system in X, Y and B
Tool breakage monitoring via external tool monitor
Deep drilling device
– Travelling support steady rest for overlong ELHB* (from a free length of 40x drilling diameter) incl. displacement and collision monitoring
– Execution 2-fold
Machine cladding with walk-on safety grids

The machine can be inspected under power. Subject to prior sale. Sale under exclusion of any guarantees and within the scope of our terms and conditions. All information without guarantee.
