Description
| Metal length | 3000 mm |
|---|---|
| Power | 4400 W |
| Metal width | 1500 mm |
| Type | CO₂ |
| Option to cut tubes | yes |
| Max thickness | 25 mm |
| CNC | yes |
| CNC type | Byvision |
| Travel X | 3048 mm |
| Travel Y | 1524 mm |
| Travel Z | 170 mm |
| Max weight of the workpiece | 890 kg |
| Length x width x height | 12900.0 × 7100.0 × 2070.0 |
| Weight | 15000 kg |
| Worked hours | 11000 hours |
| Hours under power | 29800 hours |
| State | good |
Operating hours machine: approx.29,800 h (status 01-20)
Operating hours laser: approx.11,000 h (status 01-20)
Working area X x Y x Z: 3048 x 1524 x 170 mm
laser
Laser type: DC semiconductor excitation (magnetically supported turbine)
Laser power CW: 4400 watts
Laser power range: 150 – 4400 watts
machine
CNC control: Bystronic Byvision
Cooling unit: E. Furrer WKL 430
Dust collector: Donaldson Torrit DFPRO 6 SPRK
Total electrical connection: 52 KW machine + 5.5 KW extraction
Space requirements approx .: 12,900 x 7,100 x 2,070 mm
Total weight approx .: 15,000 KG
Cuttable types of material u. Strengthen
Steel (EN 10027-1 S 235JR + AR or corresponding Raex quality) 25 mm
Inox (EN 10027-2 1.4301 (X5CrNi18-10) 20 mm
Aluminum alloys (e.g. 3.3535 AlMg3) 12 mm
Machine equipment
Standard equipment:
Cutting machine with operator protection according to occupational safety regulations in the cutting, loading and unloading area
Automatic changing table
2 cutting heads with 5 “+ 7.5“ lens
Bypos-W
Cross jet
Cut control,
Special equipment:
Pipe cutting device
Byloader with support table
Revision and description of the condition:
Maintenance and service only by the manufacturer
The machine is in production
