Description
DMG MORI CTX alpha 500 CNC Turning Center – Year 2023
Manufacturer: DMG MORI
Model: CTX alpha 500
Machine number: 0040001742C
Year of construction: 2023
Condition: like new (used)
Operating hours: 964 h
X-axis: 355 mm travel
Z-axis: 525 mm travel
Max. Turning length: 470mm
Max. Bar passage: 65 mm
Max. turning diameter: 240 mm
Max. Speed: 6000 rpm
Max. Speed of driven tools:
5000 rpm
Number of tool positions: 12
Driven tools: 12
DMG MORI CTX alpha 500 is a high-precision and accurate lathe that can handle all machinable materials. Thanks to its bar loader extension, it is ideally optimized for series production. Its counter spindle enables fast and accurate machining of both sides. In addition, the CTX has a Y-axis, which partially replaces milling work and thus ensures the fastest possible production.
Counter spindle with tailstock function Bar loader for automated production
