Description
+GF+ MIKRON MILL E 500U – Year 2018
GF Micron Mill E 500 U 5-axis Vertical Machining Center New 2018+2 5-axis Machining
Dimensions 4600 x 6590 x 3100
Weight 6030 kgs
EQUIPPED WITH
Spindle Chiller Chip Conveyor
SPEC SHEET
Control Heidenhain iTNC530
Axis travel Lengthwise X mm 500
Crosswise Y mm 450 Vertical
Z mm 400 Swivel axis º -65 / +120
Rotation axis º n x 360 Axes 3+2
Spindle Spindle type in-Line
Max. rotations min-1 12,000 rpm
Max. torque kW/Nm 20/88 Tool interface BT40 / CAT40 / ISO 40
Travel speed Rapid traverse X, Y, Z m/min 30/30/30
Rapid traverse B, C min-1 17/28
Automation Integrated tool magazine unit DT30 Tool tower unit 120 Pallet magazine unit 5 Delphin 400/400 or 5 MTS 400/400 or 7 Dynafix 350/350 or 7 UPC 320/320 Pallet changing time sec. 30 Robot interface Available Rotary swivel table T-groove table mm 500
Workpiece weight (3/5) kg 300
Dimensions 4600 x 6590 x 3100
Machine weight kg 6030
