Description
GLEASON 24A
Gear Hobbing Machine Universal Bevel CONIFLEX Straight
Max spindle speed 1500 rpm
Motor power 5.59284 kW
Weight 11297.64065 kg
CAPACITY:
Cone distance:- Max…………………………18” 457 mm
Min………………………….0 0
Pitch angle:- Max shafts at 90°………84° 18’
Min………………………….5° 42’
Extreme ratio……………………………………10:1
Coarsest diametral pitch…………………….1.25” 20.3 Module (or 1.8” max depth)
Index range………………………………………10 – 100 inclusive & most numbers to 200
WORK SPINDLE:
Diameter of taper hole at large end………6”
Taper per foot……………………………………3/4”
Depth of taper……………………………………6”
Diameter of hole through spindle………….5”
Spindle nose to machine centre……………5” – 26”
SPEEDS & FEEDS:
Cutter speeds………(13)………………………18 – 110 stroke per min
Feeds……………..(16)…………………………..24 – 686 seconds per tooth
ELECTRICAL EQUIPMENT:
Main motor………………………………………..7.5 HP @ 1500 rpm
Hydraulic pump motor…………………………2 HP @ 1500 rpm
Coolant pump motor……………………………1/2 HP @ 3000 rpm
NETT WEIGHT…………………………. 24,900 lbs
