Description
HEALD 25A Horizontal Spindle Rotary Table Surface Grinder
30″ HEALD HORIZONTAL-SPINDLE ROTARY
SURFACE GRINDER
Serial No 6939, Model 25A
EQUIPPED WITH:
Horizontal-Spindle Machine Design
30″ Diameter Magnetic Chuck
32″ Diameter Magnetic Chuck Ring
Overhead Grinding Wheel Dresser
CATALOG SPECIFICATIONS:
Magnetic Chuck, Diameter 30″
Swing With-in Coolant Guards 34″
Spindle-Center to Chuck, Minimum 7″
Spindle-Center to Chuck, Maximum 13.75″
Grinding Wheel Diameter, Minimum 14″
Grinding Wheel Diameter, Standard 18″
Grinding Wheel Width, Minimum 1/2″
Grinding Wheel Width, Standard 2″
Grinding Wheel Hole Diameter 8″
Convex Table Angle Degrees, Maximum 15-DEGREES
Concave Table Angle Degrees, Maximum 0-DEGREES
Grinding Wheel Speed, Maximum 1285 RPM
Chuck Speeds, Range 29 to 86 RPM
Spindle Motor, Horsepower 10 HP/1760 RPM
Hydraulic Motor, Horsepower/RPM 2 HP/1170 RPM
Floor Space Required, W x D 9’0″ x 6’0″
Overall Height 6’2″
Weight, Approximately 8700 LBS
