Description
Frontier (Ecoca) TZ-10 10 “CNC Lathe
Model: 2012
Flip Over Bed: Ø 420 mm
Maximum Turning Diameter: Ø 350 mm
Maximum Working Length: 480 mm
Working Capacity from Rod: Ø 65 mm
Chuck Size: 10 ”
Spindle Motor (continuous / 30 min.): 11 kw / 15 kw
Spindle Speed: 4800 rev / min
Spindle Taper: A2-6
X Axis Movement: 185 mm
Z Axis Movement: 530 mm
X Axis Motor: 3.0 kw
Z Axis Motor: 3.0 kw
X Axis Series Movement: 30 m / min.
Z Axis Series Movement: 30 m / min.
Turet Model: Hydraulic
Number of Teams: 10
Square Tool Size: □ 25 mm
Round Tool Diameter: Ø 40 mm
Tailstock Diameter: Ø 58 mm
Tailstock Movement: 88 mm
Power Requirement: 30 KVA
Cooling Tank Capacity: 100 L
Refrigerant Flow: 20 L / min.
Machine Dimension (BxExY): 2550 mm x 1550 mm x 1580 mm
Machine Weight: 3380 kg
