Description
control: FANUC 15 M
Traverse X Y Z 560 mm each,
table 400 x 400 mm,
positioning 1°,
max. pallet load 400 kg,
spindle bore 80 mm,
80 to 8000 rpm,
rapid traverse X Y Z 36 m/min,
cutting speed 0.1 to 20000 mm/min,
rotary axis (B),
pallet change time 5 s,
tool magazine with 120 places,
tool to tool change time 1.5 s,
control FANUC 15 M,
positioning precision 0.001 mm (X Y Z),
B-axis 1° (0.001° index),
repetition precision X Y Z 0.001 mm,
B-axis 1° (0.001° index)
Weight approx.: 10,500 kg
Dimensions (l x w x h) approx.: 4,300 x 2,400 x 2,800 mm
The machine are a part from a FMS . Therefore it is without
coolant system and chip conveyer. It must be dismantled.
To the Machine belongs at least 2 pallets or maybe more, Pallet changer integrated.
The Machine is still working with the FMS. It was only used for Aluminium work.
