Klingelnberg HÖFLER VIPER 500 W CNC Profile Grinding & Cylindrical Gear Grinding Machine – Year 2020
Machine type: Profile Grinding and internal Grinding machine
Manufacturer: Klingelnberg
Model: HÖFLER VIPER 500 W
Machine number: 405088
Year of construction: 2020
Condition: new
Profile Grinding and internal grinding machine is new, has not yet been put into operation due to lack of capacity, has run 0 km.
Hoffmann filter system is included.
Manufacturer Catalogue Information about Klingelnberg HÖFLER VIPER 500 W CNC Cylindrical Gear Grinding Machine :
| Range of Application | Klingelnberg HÖFLER VIPER 500 K | Klingelnberg HÖFLER VIPER 500 W | Klingelnberg HÖFLER VIPER 500 KW |
|---|---|---|---|
| GENERAL DATA | |||
| Workpiece diameter (max) | Ø 500 mm | Ø 500 mm | Ø 500 mm |
| Grinding stroke | 430 mm | 500 mm | 430 mm |
| Work area over table (min. – max.) | 370 – 800 mm | 300 – 800 mm | 370 – 800 mm |
| Distance between center above table (min. – max.) | 442 – 1,042 mm | 442 – 1,042 mm | 442 – 1,042 mm |
| Module (min. – max.) | 0.5 – 22* | 0.5 – 22* | 0.5 – 13* |
| Swivel angle | –180°/+ 45° | –180°/+ 45° | –180°/+ 45° |
| Grinding wheel diameter (max.) | Ø 300 – 25 mm | Ø 350 – 221 mm | Ø 300 – 25 mm |
| Grinding wheel width (max.) | 60 mm | 75 mm | 60 mm |
| Grinding worm diameter | – | Ø 350 – 221 mm | Ø 200 – 111 mm |
| Grinding worm width | – | 150 mm | 80 mm |
| Grinding spindle | 35 kW | 37 kW | 35 kW |
| Grinding wheel speed | 17,000 rpm | 6,000 rpm | 17,000 rpm |
| Table diameter | Ø 400 mm | Ø 400 mm | Ø 400 mm |
| Table load (max.) | 500 kg | 500 kg | 500 kg |
| Table hole (diameter x depth) | Ø 100 x 500 mm | Ø 100 x 500 mm | Ø 100 x 500 mm |
| Table rotation speed (max.) | 120 rpm | 1,000 rpm | 1,000 rpm |
| Axial feed rate (max.) | 20,000 mm/min | 20,000 mm/min | 20,000 mm/min |
| Radial feed rate (max.) | 12,000 mm/min | 12,000 mm/min | 12,000 mm/min |
| Tangential feed rate (max.) | 20,000 mm/min | 20,000 mm/min | 20,000 mm/min |
| GENERAL MACHINE DATA | |||
| Total connected load without filter system | 60 kVA | 60 kVA | 60 kVA |
| Net weight approx. | 19,300 kg | 19,300 kg | 19,300 kg |
| Machine dimensions (L x W x H) approx. | 4,220 x 3,120 x 2,526 mm | 4,220 x 3,120 x 2,526 mm | 4,220 x 3,120 x 2,526 mm |
| Dimensions filter unit (L x W) approx. | 3,450 x 2,100 mm | 3,490 x 2,250 mm | 3,490 x 2,250 mm |
Klingelnberg HÖFLER VIPER 500
HÖFLER CYLINDRICAL GEAR GRINDING MACHINE
CONVERTIBLE MACHINE FOR INDIVIDUAL REQUIREMENTS
The VIPER 500 cylindrical gear grinding machine is designed for component diameters up to 500 mm and is optimally suited for small to medium-sized batches. To suit individual requirements, the machine is available in three different configurations: Profile grinding with small grinding wheels for custom jobs and multiplewheel technology (K), as well as generating grinding (W) or (KW). The VIPER 500 W / KW configuration allows both profile grinding and continuous generating grinding on the same machine – with minimal retooling time.
Convertible machine for generating, profile, and internal grinding (VIPER 500 W)
Retooling from generation grinding to profile grinding in less than 5 minutes (VIPER 500 W)
Retooling to internal grinding in less than 15 minutes
Highly dynamic axes at 5 m/sec2 acceleration and 20 m/min rapid traverse
Low-maintenance machine concept due to separation of working chamber from drive technology
No pump station needed for grinding oil
Optimal energy efficiency (e2) thanks to recovery and on-demand powering of units
HIGHLIGHT
HÖFLER CYLINDRICAL GEAR GRINDING MACHINE Klingelnberg HÖFLER VIPER 500
DYNAMIC, ACCELERATED PRODUCTION PROCESSES
Special machine axis arrangement guarantees high reliability in the production process
Automatic adjustment of the grinding oil nozzles ensures the same process for every grinding wheel diameter
Automatic grinding stock analysis
Adaptive process sequences thanks to variable stroke rate and dressing
Measurements taken during the production process itself (including optional correction calculation in the machine) provide quick assurance of a successful production run
CONVENIENT, CLEARLY LAID-OUT OPERATING CONCEPT
Intelligent control technology with fast, rational and intuitive dialog input and job engineering
Clear navigation and visual workflow support prevent user errors
Continuous graphical display of machine statuses and processes
Graphical display of possible workpiece clamping collisions before the problem occurs on the machine
MINIMAL RETOOLING TIMES
Quick changeover from generating grinding to profile grinding just by swapping out the grinding wheel, grinding wheel flange, and diamond dressing roll in less than 5 minutes (VIPER 500 W)
Quick grinding wheel changes using the swivel axis, which moves the grinding wheel 180 degrees toward the operator
Tool quick-clamping system enables fast and easy tool changes (VIPER 500 W)
Short retooling times for internal grinding in less than 15 minutes
MAXIMUM PRODUCTION TECHNOLOGY, MINIMAL FOOTPRINT
Small setup dimensions means less floor space needed at the installation location
Self-contained construction for ultra-easy machine transport and setup
Fast cleaning time, since all installations are accommodated outside the working chamber
All machine components are quickly and easily accessible
Easy, ergonomic adjustment of the oil supply
TECHNOLOGY PLATFORM FOR PROFILE AND GENERATION GRINDING
Extensive configurations enable profile and continuous generating grinding on the same machine (VIPER 500 W)
Application-appropriate machine design allows tremendous variety in the work range
Easy, ergonomic handling ensures quick and seamless product changeover
Powerful dressing unit for cost-effective, precise dressing of the grinding wheels with all the usual modifications
Highly dynamic drives for maximum precision
CLOSED LOOP QUALITY CONTROL IN LINE WITH INDUSTRY 4.0
Central gearing and process design
Networked connection in the Klingelnberg production system
(GearEngine®)
Knowledge management with central production data acquisition
Digitization of gear production through automated machine correction
Innovative Cylindrical Gear Machining for Flexible Requirements
All around the world, manufacturers of gears and transmissions ensure their leading edge in gear machining with
innovative solutions by Klingelnberg. High research and
development standards, a global service network, and an
in-house application engineering service ensure a leadership position – now and in the years to come – thanks to
our decades-long expertise and high innovation capacity.
The Höfler Cylindrical Gear Technology division makes
economical, high-precision production of cylindrical gears
a reality for customers, with a portfolio that includes cylindrical gear grinding machines for generating grinding,
profile grinding, and internal gear grinding, among others. A key factor in the successful completion of each work
step is the Gear Production software, providing optimal
process control and extreme ease-of-operation to guarantee maximum efficiency in the daily production routine.
Klingelnberg also consistently strives to develop innovations and solutions to enhance productivity – and sets the
same standard for measuring technology. Machine tool
networking with the Klingelnberg Precision Measuring
Centers creates a digital process and quality control system
within the Closed Loop concept. Klingelnberg also offers
individual services. In addition to
machine maintenance and repair,
a number of upgrade options and
add-on functions are available.
Höfler cylindrical gear machines
are developed with real-world
applications in mind and satisfy
a whole host of application industry requirements. Customers
include contract gear manufacturers and gearbox manufacturers in
the aviation, automotive, mining,
construction, industrial gearbox,
maritime drive technology, and
wind power industries.
Leading Technology for a Fast,
Efficient Production Process
The VIPER 500 cylindrical gear grinding machine is designed for
component diameters up to 500 mm and is optimally suited for
small to medium-sized batches. To suit individual requirements,
the machine is available in three different configurations:profile
grinding, small grinding wheels for custom jobs and multiplewheel technology (K), as well as generating grinding (W) or (KW).
The VIPER 500 W / KW configuration allows both profile grinding and continuous generating grinding on the same machine
– with minimal retooling time. To change the grinding technology, just swap out the grinding wheel, the grinding wheel
flank, and the diamond dressing roll. On all variants, the optional internal gear grinding arm allows retooling from external to internal gearing.
Moreover, the special machine axis arrangement is a contributing factor in the machine’s tried-and-tested precision and consistent quality, as well as tremendous flexibility. The highly dynamic axes allow optimized 5-axis machining of an entire range
of modifications in the shortest possible grinding time. The innovative design also makes for easy cleaning and high performance capacity while achieving significant energy savings.
Moreover, the Gear Production software developed in-house
guarantees ease-of-use, even for complex applications. (See
page 10 for more information on the Gear Production software.)
Highly adaptable machine for
generating, profile, and internal
grinding
Retooling from generating grinding to profile grinding in less than
5 minutes
Retooling to internal grinding in
less than 15 minutes
Highly dynamic axes allow stroke
feeds up to 20 m / min
Low-maintenance machine concept due to separation of working
chamber from drive technology
No pump station needed for the
grinding oil Optimal energy efficiency thanks to recovery and on
demand control of units
