Knuth Portamill PBZ Heavy 2025 CNC Double Column Bridge Type Machining Center – Year 2010

Contact us for price

Description

Knuth Portamill PBZ Heavy 2025
CNC Double Column Bridge Type Machining Center – Year 2010

Brand:Knuth
Model: Portamill PBZ Heavy 2025
Year:2010
Approx. Shipping Weight:101,200 Lbs.
Approx. Shipping Dimensions:307″ x 228.3″ x 216.5″
Spindle Taper:BT50
X Travel:110.2″
Y Travel:106.3″
Z Travel:47.2″
Table Size:63″ x 98.4″
Max Table Load:17,600 Lbs.
Spindle Nose to Table Distance:7.9″ – 55.1″
Spindle Speed:30-6000 RPM
Spindle Motor:35HP
Rapid Feed:400 IPM X & Y / 315 IPM Z
Work Feed:.01 – 200 IPM
Tool Changer Capacity:40
Max Tool Diameter:9.8″
Max Tool Length:19.7″
Max Tool Weight:44 Lbs.

Equipped With
40 Station Tool Changer, Fanuc 0I MC Control, Chip Conveyor, Electric Handwheel

Additional Info
Machine is under power
