Description
Mägerle FPA 10 S4.2 – Year 1976
Surface grinder fuer profile grinding Machine
Table length: 1050 mm
Table width: 240 mm
Grinding length: 1000 mm
Grinding width: 320 mm
Grinding height: 365 mm
Max. distance from table to spindle-centreline: 515 mm
Longitudinal travel (X-axis): 1130 mm
Transversal travel (Y-axis) 270 mm
Automatic cross-feed: 7 m/min
Table feed: 30 m/min
Automatic vertical feed: 0.030 mm
Vertical rapid traverse: 0.30 m/min
Diameter of grinding wheel: 300 mm
Width of the grinding wheel: 160 mm
Grinding wheel speeds: 3340 rpm
Voltage 50 Hz, 3x 380 V
Machine weight: 5800 kg
Overall machine dimensions: 2800 x 1600 x 2700 mm
Rich accessories
