Description
MAZAK NEXUS 6800-II – Year 2015
| Axis X | 1050 mm |
|---|---|
| Axis Y | 900 mm |
| Axis Z | 980 mm |
| Rotary table (4th axis) | yes |
| Table length | 630 mm |
| Number of tool pockets | 43 |
| Spindle taper | BT50 |
| Max. spindle speed | 10000 rpm |
| Spindle motor power | 30 kW |
MAZAK HORIZONTAL CENTER NEXUS 6800-II
Maximum workpiece diameter 1,050 mm
Maximum workpiece height 1,300 mm
X-axis 1,050 mm
Y-axis 900 mm
CAPACITY Z-axis 980 mm
Spindle taper hole 7/24 taper No. 50
Spindle speed maximum 10,000 min-¹
SPINDLE (standard) Main motor 30.0 kW
FEED RATES Rapid traverse (X/Y/Z) 60 m/min
Pallet width 630 mm
TABLE & PALLET Pallet length 630 mm
No. of tool pockets (standard) 43
ATC TOOL MAGAZINE Tool shank BT 50
Width 3,301 mm
MACHINE SIZE Length 5,741 mm
Coolant through Spindle 70 bar
Controller Mazatrol
