Description
MAZAK PMU POWER MASTER OILFIELD CNC Heavy Duty Lathe 24 Inch 3 Meters – Year 1997
EQUIPPED WITH:
Mazak Mazatrol T-Plus CNC Control, Mazatrol Conversational Programming
Front and Rear Chucks, 10.2″ Thru Hole, 8 Position Disc Turret, 6 Station ID
Boring Turret, Hardened Bed and Cross Slide Ways, Ballscrews,
Heavy Duty Tailstock w/ Hydraulic Quill, Steady Rest, Chip Conveyor and Coolant System.
Max Swing Over the Bed……………………………. 34″
Max Swing Over Cross Slide………………………… 22″
Max Tailstock Position……………………………. 123″
Max Machinable Center Distance…………………….. 120″
Chuck Size………………………………………. 24″
Cross Travel (X-Axis)…………………………….. 22″
Longitudinal Travel (Z-Axis)………………………. 121-3/8″
Cross Feed Range (.01 Increment)…………………… 263 IPM
Longitudinal Feed Range (.01 Increment)…………….. 315 IPM
Number of Turrets………………………………… 2
Tool Positions ID Turret………………………….. 8
Tool Positions OD Turret………………………….. 6
Spindle Bore…………………………………….. 10.2″”
Spindle Nose…………………………………….. A1-20
Spindle Speeds (12), Range………………………… 2-750 RPM
Spindle Horsepower……………………………….. 60 HP
Tailstock Spindle Taper…………………………… #5 MT
Electrics……………………………………….. 460/3/60
Approximate Machine Dimensions…………………….. 250″ x 130″
Approximate Machine Height………………………… 76″
Approximate Machine Weight………………………… 28,000 LBS
