Description
O-M VT1-16 Vertical Boring Mill – Year 1970
MODEL: VT1-16,
S/N: MN701926,
BRAND : 1970
SPECIFICATIONS:
TABLE DIAMETER ……………………….. 63″
MAX TURNING DIAMETER ………………….. 71″
MAX TURNING DIAMETER WITH SIDE HEAD IN PLACE 65″
MAX TURNING HEIGHT ABOVE TABLE …………. 54-3/8″
VERTICAL TRAVERSE OF TURRET HEAD ……….. 38-5/8″
HORIZONTAL TRAVERSE OF TURRET HEAD ……… 43-3/8″
VERTICAL TRAVEL OF CROSS RAIL ………….. 44-1/2″
MAXIMUM WEIGHT OF WORK PIECE ON TABLE …… 15,400 LBS.
SWIVEL OF TURRET HEAD PLUS OR MINUS …….. 30 DEGREES
(12) TABLE SPEEDS …………………….. 3.6 TO 200 RPM
(24) FEEDS, TURRET & SIDE HEADS ………… 0.0025 – 0.11 IPM
POWER RAPID TRAVERSE RANGE, TURRET & SIDE HEADS 104 IPM
POWER RAPID TRAVERSE RANGE, CROSS RAIL ….. 18-7/8 IPM
MAX HEIGHT WITH HEAD & RAIL IN UP POSITION . 186″
EQUIPPED WITH:
– 63″ DIAMETER FACEPLATE WITH A SET OF HARDENED TOP JAWS
– 3-SPEED GEAR BOX IN CONJUNCTION w/ A FOUR POLE TABLE DRIVE MOTOR ALLOWING FOR (12) TABLE SPEEDS
– SWIVEL-TYPE PENTAGONAL TURRET HEAD WITH MANUAL INDEXING
– RIGHT HAND SIDE SIDE HEAD WITH SQUARE TURRET TOOLPOST
– FULL PENDANT CONTROL
– DIGITAL READOUT
– HARDENED CROSS RAIL WAYS
– HARDENED WAYS ON TURRET SLIDE
– 4 H.P. CROSS RAIL RAPID TRAVERSE MOTOR
– 5 H.P. RAIL ELEVATION MOTOR
– 40-30-25-20 H.P. FOUR-SPEED MAIN DRIVE MOTOR AND ELECTRICAL CONTROLS
