Description
Prasmatic MSW 300 C Sealer – Year 2012
Packaging Machinery Shrink Wrap Sealer
| Output | 35 u/mn |
| Prasmatic MSW 300 C Sealer | |
| Weight | 80 kg |
Technical data of the PRASMATIC MSW 300C packaging machine
– packing speed: 35 packs/min
– maximum roll diameter: 500 mm
– maximum roll width: 680 mm
– maximum roll weight: 80 kg
– average resizing time: 10 – 25 min
– brushless motors
– touch screen control panel
– rated current: 65A
– power supply: 400V; 50 Hz
There is also an option to purchase the entire packaging line. Such a line includes:
– bottle packing machine: PRASMATIC MSW 300/C
– feeding table
– roller conveyor – gravitational, 440 mm wide and 3000 mm long
– inlet table for the packaging machine with dimensions of 2000 x 800 mm
– single-row conveyor with a length of 1000 mm
– four-row 90° bend with a length of 2400 mm
– 90° bend with straight sections 3000 mm long
PRASMATIC MSW 300 C packaging machine, manufactured in 2012 in Italy, is designed for automatic wrapping of products, i.e. bottles or, for example, cans with heat-shrinkable foil into packs of, for example, 6-9 products. The state-of-the-art technology used in the machine optimizes the packaging cycle, ensuring the highest production efficiency. Control of the unwinding and winding speed with brushless motors and the system of cold film cutting through a rotating blade guarantee the correct feeding of the film. The shrink wrapping machine was used for only two months a year, which is why it has a very low mileage for this type of machine.
