Description
Faceplate diameter | 2090 mm |
---|---|
Turning speed | 200 rpm |
Length x width x height | 1850.0 × 2090.0 × 2150.0 |
Weight | 8950 kg |
X AxisTraverseTop Slide 750mm +Saddle 700mm, By hand or power
Z Axis TraverseSaddle 200mm + Compound Slide 350mm By hand or power
Input380/3/50hz
Spindle Speeds6 – 200 rmp
Face Plate Diameter2090mm
Tool post4 Way
LengthHeadstock, 1850mm. Saddle, 1750mm.
WidthHeadstock, 2090mm. Saddle, 1100mm.
HeightHeadstock, 2150mm, Saddle, 1450mm.
Nett weight actual.8,950 Kgs. / 8.9 Tons.
