Description

WINDMÖLLER & HÖLSCHER Miraflex CI Flexo 8 Colours Printing Line – Year 2012
TECHNICAL SPECIFICATIONS:
Printing Width: 1270 mm
Web Width: 1320 mm
Printing Repeat (Max): 800 mm
Printing Repeat (Min): 370 mm
Drying System: Oil burner
System: Gearless
OTHER SPECIFICATIONS:
Material width min. 750 mm
Machine speed max. 500 m/min
.
Materials to be processed
LDPE, PP, PA 20 – 150 micras
HDPE, OPP 12 – 100 micras
Composite films up to 150 micras
Paper 30 – 120 g/m²
PET, OPA, BOPP 10 – 30 micras

Unwinding
Winding type NON-STOP for shaftless operation
Roll width max. 1,320 mm
Roll diameter max. 1,016 mm
Roll weight 1,240 kg
Inner core diameter 70 / 76 mm
Sleeve outer diameter min. 90 mm
Web tension range 25 – 300 N
Underfloor roller lift for unwinding without axes

Rewinding
Winding type NON-STOP for shaftless operation
Roll width max. 1,320 mm
Roll diameter max. 1,016 mm
Roll weight max. 1,240 kg
Core diameter 70 / 76 mm
Web tension range without slitter operation 25 – 350 N
with longitudinal cutter operation 40 – 350 N
Underfloor roller lift for unwinding without axes

Control
Procontrol W&H
WEB – VIDEO BST
Viscosimeter Bloss

Printing unit
Inking units with Turboclean 8

Print monitoring Mirror drum device: for visual print image and quality monitoring of the running materials
Pre-treatment AFS unit after rewinding, to generate a surface tension of a surface tension of 38 – 44 mN/m (dyn)
Edge suction device with adjustable suction nozzles and injector tubes

Accessories
Longitudional cutting unit

15 Anilox pieces
110l/cm 60°
110l/cm 60°
140l/cm 60°
220l/cm 60°
250 l/cm 60°
250 l/cm 60°
250 l/cm 60°
250 l/cm 60°
250 l/cm 60°
250 l/cm 60°
250 l/cm 60°
250 l/cm 60°
360 l/cm 60°
360 l/cm 60°
460 l/cm 60°

4 additional doctor blades
2 x 6 inch winding shafts
2 x 3 inch winding shafts
8 x supply and return nozzles for paint buckets
16 stainless steel paint containers (volume: 15 liters)

Guarantee: Without guarantee
Current condition: In Production
Availability: Immediate
