Description
Workspace
Table dimensions: 1200 x 500 mm
table load capacity: 500 kg
Traverse path X-axis: 1020 mm
Stroke y axis: 510 mm
Z axis travel: 530 mm
Rpm: 12,000 min-1
Spindle retainer: BT 40
Rapid traverse x axis: 30,000 mm / min
Rapid traverse y axis: 30,000 mm / min
Rapid traverse Z axis: 20,000 mm / min
Working feed: 15.00 mm / min
Number of tool stations: 24
Tool length (max): 300mm
Tool diameter. (max): 120mm tool weight (max.): 15 kg
Time for tool change, chip/chip: 7s
Drive outputs
Main drive motor power: 15/11 kW
Mass and weight-
Dimensions: 3100 x 2500 x 2600 mm
Weight: 6100 kg
* ALL IN package VN-1000 *.
-Automatic power shut-off at end of work
-Kuehlmittel-& rinse-gun
-Electronic hand wheel coolant through spindle
Air cooling
-Siemens 828 D with ShopMill / Fanuc 0IMD
Signal lamp
Chip car
Chip conveyor
Free delivery to your door
-Incl. commissioning
-1 day training
