The IGF (Interactive Graphics Function) conversational option on OKUMA CNC Turning Center machines is a powerful feature that simplifies programming by allowing operators to create CNC programs directly on the machine using a user-friendly, graphical interface. Here’s how it works and its main benefits:

1. Interactive Programming

• Graphical Interface: The IGF option uses a graphical interface that allows operators to input part dimensions, features, and machining operations interactively. Instead of writing complex G-code manually, the operator simply follows intuitive prompts on the screen.
• No G-Code Knowledge Required: Since the system generates the G-code in the background, even operators with limited knowledge of CNC programming can produce accurate and efficient programs.

2. Simplified Workflow

• Part Drawing Interpretation: IGF can interpret simple part drawings and automatically generate the required toolpaths. Operators input basic geometrical features (such as diameters, lengths, and angles), and the system automatically processes this data to produce the machining program.
• Real-Time Feedback: The system provides real-time feedback by showing the toolpath on-screen, allowing operators to visualize the entire machining process before execution. This reduces errors and ensures accurate setup.

3. Optimized Machining Process

• Auto-Generated Toolpaths: Once the operator inputs the required features, the IGF system generates the most efficient toolpaths for machining the part. It selects optimal speeds, feeds, and cutting depths, maximizing machine productivity.
• Reduced Setup Time: IGF reduces programming and setup time by eliminating manual coding and making adjustments directly from the machine interface.

4. Customization and Flexibility

• Adjustable Machining Parameters: Operators can still make adjustments to machining parameters such as tool selection, cutting speed, and depth of cut after the program is generated. This flexibility is crucial for fine-tuning programs based on material properties and machining conditions.
• Adaptive Control: The system can adapt to specific part features, allowing for precise control over cutting operations. For example, it can accommodate complex turning operations, threading, or grooving by providing relevant graphical inputs.

5. Program Storage and Reuse

• Easy Program Management: Once a program is created using IGF, it can be saved and reused for similar jobs in the future, streamlining production and improving repeatability.
• Editing and Modification: Programs generated by IGF can be easily edited through the graphical interface, making it simpler to adjust for changes in part specifications.

Why Customers Prefer IGF on OKUMA CNC Turning Centers:

• Ease of Use: The conversational programming eliminates the steep learning curve associated with traditional CNC programming.
• Time Efficiency: Programming is quicker, reducing downtime and increasing machine utilization.
• Error Reduction: The graphical interface minimizes programming errors, improving part quality and consistency.

In summary, the IGF conversational option on OKUMA CNC Turning Centers is designed to enhance operator productivity by simplifying the programming process through an intuitive, graphics-based system. It’s ideal for both experienced machinists and those with limited CNC programming knowledge, ensuring efficient, accurate, and error-free machining operations.
